Description

The Crestron Flex UC-B30-Z system provides a video conference room solution for use with Zoom Rooms software. It supports a single video display1 and features a 10.1 in. touch screen (TS‑1070‑B‑S), UC Bracket Assembly (UC-BRKT-200-S-Z-ASSY), and Crestron UC video conference smart soundbar & camera (UC-SB1-CAM-FLEX).

Key Features

  • Front‑of‑room video conferencing solution for Zoom Rooms™ software
  • Native Zoom Rooms touch screen UI provides a consistent user experience with simple operation and one‑touch meeting joins
  • Complete kit contains a 10.1 in. touch screen, Crestron® smart soundbar and camera, UC bracket assembly, and PoE injector— just add a display and mount
  • Easy to specify and install — no custom design, programming, or software installation required
  • Network management and provisioning and system alerts through the XiO Cloud® service
  • Premium‑level support with Crestron Flex Care (optional)
  • Enterprise-grade security - connects and communicates securely over any enterprise or SMB network
  • Supports a single video display

The Crestron Flex UC-B30-Z system provides a video conference room solution for use with Zoom Rooms software. It supports a single video display1 and features a 10.1 in. touch screen (TS‑1070‑B‑S), UC Bracket Assembly (UC-BRKT-200-S-Z-ASSY), and Crestron UC video conference smart soundbar & camera (UC-SB1-CAM-FLEX).

Native Zoom Rooms™ Software Experience

The UC-B30-Z system features Zoom Rooms conferencing software that enables audio and video connectivity for easy collaboration and content sharing.

Intuitive User Interface

With a large 10.1 in. (257 mm) capacitive touch screen display, the Crestron® tabletop touch screen (TS‑1070‑B‑S) provides superior conferencing control in meeting rooms, huddle spaces, and executive offices. The touch screen also offers optional control of room lighting, shades, thermostats, and other equipment.

Simplified Deployment

The UC Bracket Assembly (UC‑BRKT‑200‑S‑Z‑ASSY) provides preassembled components on one ready-to-mount bracket to simplify installation. The assembly can be mounted on a wall, or it can be attached to the rear of the display device.

High‑Definition Video Conferencing with Impressive Audio

High-quality speakers, microphone, and digital signal processing deliver exceptional full-duplex speakerphone performance from the Crestron UC video conference soundbar and camera (UC-SB1-CAM-FLEX). The built-in conferencing camera captures the room in HD 1080p video resolution and with an ultra-wide 150° diagonal field of view.

Enterprise‑Grade Security

Crestron Flex is an enterprise‑grade solution that is ideally equipped for mass deployment throughout any sized corporate, university, medical, military, or government facility.

Easy Provisioning and Device Management

The XiO Cloud service3 is an IoT cloud based provisioning service that enables installers and IT managers to deploy and manage thousands of devices easily. The XiO Cloud service allows for system alerts, network management and provisioning, and the pairing of a control device to the system’s UC Engine. System updates are controlled by Windows® software update.

Included Components
TS‑1070‑B‑S 10.1 in. (257 mm) tabletop touch screen, black
UC‑BRKT‑200‑S‑Z‑ASSY UC Bracket Assembly for Zoom Rooms systems, comprised of:
  • UC-ENGINE-S-Z: UC Engine for Zoom Rooms video
  • HD-CONV-USB-200: HDMI® to USB 3.0 converter for content ingest
  • Mounting hardware
UC‑SB1‑CAM‑FLEX UC Video Conference Smart Soundbar and Camera
CBL-CAT5E-7  Ethernet LAN cable for UC Engine, RJ45-to-RJ45, black, 7 ft (2.1 m)
CBL‑HD‑6 HDMI Interface Cable, 6 ft (1.8 m)
CBL‑HD‑20 HDMI Interface Cable, 20 ft (6.1 m)
PWE-4803RU PoE Injector
EDID Passthrough HDMI Female‑to‑Male
Tabletop Touch Screen
Touch Screen 10.1 in. (257 mm) diagonal capacitive multi-touch TFT active matrix color LCD, 1920 x 1200 pixels
UI Zoom Rooms UI plus optional Crestron Smart Graphics® room control UI2
Ethernet 100 Mbps, auto switching, auto negotiating, auto discovery, full/half duplex, TCP/IP, UDP/IP, CIP, DHCP, SSL, TLS, SSH, SFTP (SSH File Transfer Protocol), IEEE 802.1X, SNMP, IPv4 or IPv6, Active Directory® service authentication, HTTPS web browser setup, XiO Cloud® client, IEEE 802.3at compliant
Power over Ethernet IEEE 802.3at Type 2 compliant PoE+ PD (Powered Device);
Normally requests 15 W from an 802.3at Type 2 PSE with LLDP advanced power management;
With room scheduling and USB enabled, requests 18 W from an 802.3at Type 2 PSE with LLDP;
Requests 30 W (PoE+ Class 4) from an 802.3at Type 2 PSE without LLDP;
Requests 15.4 W (PoE Class 0) from an 802.3af (or 802.3at Type 1) PSE
PoE Injector A PoE injector is included to power the touch screen if network PoE is not available
Construction Plastic, smooth black finish, edge-to-edge glass with black surround
Dimensions Height: 5.29 in. (134 mm)
Width: 9.63 in. (245 mm)
Depth: 4.67 in. (119 mm)
Weight 2.44 lb (1105 g)
Smart Soundbar and Camera
Speakers Stereo 2‑way, 20 W per channel;
3 in. (76 mm) woofers;
3 x 4-3/8 in. (76 x 112 mm) passive radiators;
1 in. (25 mm) dome tweeters;
80 Hz to 20 kHz (±3 dB) frequency response;
91 dB SPL @ 1 m output level (both channels driven at full power)
Microphone Linear quad-element far-field adaptive beamforming microphone array;
15 ft (4.6 m) pickup range,4 180° horizontal and 180° vertical pickup angle;
20 Hz to 8 kHz frequency response
Audio DSP Acoustic echo cancellation, dereverberation, automatic gain control, dynamic noise suppression, adaptive beamforming, speaker volume control, speaker EQ and limiting (fixed);
Full-duplex IEEE 1329 Type 1 compliant
Camera Optics 12 Megapixel 1/2.3 CMOS sensor, ultra wide angle six element aspherical glass lens, f/2.8 aperture
Camera Field of View 150º diagonal, 120º horizontal, 90º vertical
Autozoom Genius Framing automatic lossless digital zoom intelligently frames around people in the room
Camera Noise Reduction 3D noise reduction, bias compensating spatio-temporal filtering, wide area chroma filtering, flicker elimination
Camera Scaling Real-time scaling, dewarping, and perspective correction
Camera Resolution HD 1080p @ 30 fps
Analog Audio Input 2-Channel stereo via 3.5 mm TRS mini-phone jack, fixed level (bypasses DSP), 1 Vrms maximum per channel for full rated output, for in-room amplification of an external audio source
Analog Audio Output 2-Channel stereo via 3.5 mm TRS mini-phone jack, fixed level, 1 Vrms maximum, feeds amplified audio content to an assistive listening system
Status Bar Multi-segment RGBY LED zero-center mutually-diverging linear bargraph
Main Power 24 VDC via external 100‑240 VAC, 50/60 Hz power pack, model PW‑2420RU(included)
Enclosure Lightly textured gunmetal black finish, plastic housing, perforated stainless steel grilles, die-cast aluminum rear cover, integral steel hinged mounting bracket
Mounting Freestanding or surface wall mount at ear/face level (adhesive feet included, mounting bracket attached)
Dimensions Height: 4.57 in. (116 mm), 4.64 in. (118 mm) with feet
Width: 43.60 in. (1107 mm)
Depth: 3.90 in. (99 mm)
Weight 13.56 lb (6.2 kg)
UC Bracket Assembly
Mini PC Intel Core® processor with Windows® 10 IOT Edition OS
UC Client Zoom Rooms software
Management Client XiO Cloud Service
Content Ingest HDMI input via HDMI to USB 3.0 converter (model HD‑CONV‑USB‑200)
Display Output Single display support
Display Output Resolution 1080p
Power 65 W via external 100‑240 VAC, 50/60 Hz adapter (included)
Construction Metal mounting bracket, black, preassembled with UC‑ENGINE‑S‑Z and HD‑CONV‑USB‑200
Mounting Surface wall mount behind the display device, or attach to the rear of the display device via the bolts attaching the display to a VESA® compliant display mount;
Bracket includes mounting holes on both side edges, spaced 100, 200, and 300 mm vertically, to allow for attachment to either side of the display mounting plate
Dimensions Height: 15.00 in. (381 mm)
Width: 14.50 in. (368 mm)
Depth: 1.72 in. (44 mm)
Weight 6.64 lb (3 kg)
