Crestron Flex Advanced Tabletop Large Room Video Conference System for Zoom Rooms™ Software

(No reviews yet) Write a Review
SKU:
UC-MX70-Z
  • Crestron Flex Advanced Tabletop Large Room Video Conference System for Zoom Rooms™ Software
  • Crestron Flex Advanced Tabletop Large Room Video Conference System for Zoom Rooms™ Software
  • Crestron Flex Advanced Tabletop Large Room Video Conference System for Zoom Rooms™ Software
  • Crestron Flex Advanced Tabletop Large Room Video Conference System for Zoom Rooms™ Software
  • Crestron Flex Advanced Tabletop Large Room Video Conference System for Zoom Rooms™ Software
  • Crestron Flex Advanced Tabletop Large Room Video Conference System for Zoom Rooms™ Software
  • Crestron Flex Advanced Tabletop Large Room Video Conference System for Zoom Rooms™ Software
  • Crestron Flex Advanced Tabletop Large Room Video Conference System for Zoom Rooms™ Software
  • Crestron Flex Advanced Tabletop Large Room Video Conference System for Zoom Rooms™ Software
  • Crestron Flex Advanced Tabletop Large Room Video Conference System for Zoom Rooms™ Software

Description

The UC-MX70-Z system provides a complete video conference room solution for use with the Zoom Rooms software. It supports single or dual video displays, and features the Crestron Flex tabletop conference device, UC Bracket Assembly with UC‑ENGINE, an enterprise-grade camera, mic pod, cables, and power supply.

Key Features

  • Tabletop video conferencing solution for Zoom Rooms™ software
  • Present, call, conference, and collaborate using your own device's UC conference platform (BYOD) or the native Zoom Rooms platform
  • Native Zoom Rooms touch screen UI provides a consistent user experience with simple operation and one‑touch meeting joins
  • Complete kit contains the Crestron Flex tabletop conference device, UC Bracket Assembly, an enterprise-grade camera, mic pod, cables, and power supply — just add display(s) and mount
  • Easy to specify and install — no custom design, programming, or software installation required
  • Network management and provisioning and system alerts through the XiO Cloud® service
  • Premium‑level support with Crestron Flex Care (optional)
  • Enterprise‑grade security ‑ connects and communicates securely over any enterprise or SMB network

The UC‑MX70‑Z system provides a complete video conference room solution for use with Zoom Rooms software. It supports single or dual video displays1, and features the Crestron Flex tabletop conference device (CCS‑UC‑1‑X), UC Bracket Assembly with UC‑ENGINE (UC‑BRKT‑250‑P‑Z‑ASSY), an enterprise-grade camera (UC‑CAM‑HD‑520), mic pod (CCS‑UCA‑MIC), cables, and power supply.

Native Zoom Rooms™ Software Experience

The UC-MX70-Z system features Zoom Rooms conferencing software that enables audio and video connectivity for easy collaboration and content sharing.

Intuitive User Interface with Impressive Audio

The Crestron Flex tabletop conference device (CCS-UC-1-X) provides a superior conferencing and collaboration experience with its large 7 in. HD display, integrated 360° quad microphone array, and an AEC-enabled USB speakerphone that supports full-duplex wideband audio performance.

Simplified Deployment

The UC Bracket Assembly (UC‑BRKT‑250‑P‑Z‑ASSY) provides preassembled components on one ready-to-mount bracket to simplify installation. The assembly can be mounted on a wall, or it can be attached to the rear of the display device.

High-Definition Video Conferencing

The included enterprise-grade camera (UC-CAM-HD-520) features a wide-angle 82° diagonal field of view to capture the conference room in Full HD 1080p video resolution. High precision aspherical optics, super low light 2M pixel sensor, and advanced video processing ensure a clear video image free from light or noise artifacts.

Bring Your Own Device (BYOD)

Conference room visitors can connect their laptop to the Crestron Flex system to use their own UC conference platform. The UC-MX70-Z's built-in content ingest device switches to the connected laptop's UC platform and returns to the native Zoom Rooms platform when disconnected.

Enterprise-Grade Security

Crestron Flex is an enterprise-grade solution that is ideally equipped for mass deployment throughout any sized corporate, university, medical, military, or government facility. Its advanced security features ensure privacy, reliability, and compliance with your organization’s IT policies.

Easy Provisioning and Device Management

The XiO Cloud service2 is an IoT cloud-based provisioning service that enables installers and IT managers to easily deploy and manage thousands of devices. The XiO Cloud service allows for system alerts, network management and provisioning, and the pairing of a control device to the system’s UC Engine. System updates are controlled by Windows® software update.

Included Components
UC‑BRKT‑250‑P‑Z‑ASSY UC Bracket Assembly for Zoom Rooms systems, comprised of:
  • UC‑ENGINE-P-Z: UC Engine for Zoom Rooms systems
  • HD‑CONV‑USB‑250: CAT5 to USB 3.0 converter for content ingest
  • Mounting Hardware
CCS‑UC‑1‑X Crestron Flex tabletop conferencing device includes:
  • PW-2420RU Universal power supply and power cord
  • Cable, CAT5e, RJ‑45‑to‑RJ‑45, 12 ft (3.66 m)
  • Cable management hardware
CCS-UCA-MIC Extension microphone pod
UC-CAM-HD-520 Enterprise-grade camera
CBL‑CAT5E‑7 Ethernet LAN cable, CAT5e, RJ‑45‑to‑RJ‑45, black, 7 ft (2.1 m)
CBL‑HD‑THIN‑HS‑6 Thin HDMI cable for connecting display device, Type A male‑to‑male, 6 ft (1.8 m)
CBL-USB-A-BMICRO-6 USB 2.0 A - Micro-B cable, 6 ft (1.8 m)
CBL‑HD-6 HDMI Interface Cable, 6 ft (1.8 m)
CBL‑4K‑DP‑HD-6 Active Converter Cable, DisplayPort™ to HDMI®, 18 Gbps, 6 ft (1.8 m)
DM-CBL-ULTRA-PC-20 (2) Ethernet LAN cable for touch screen, CAT6a, RJ‑45‑to‑RJ‑45, blue, 20 ft (6 m)
PW‑2420RU Universal power supply and power cord
EDID passthrough (2) HDMI Female-to-Male
Crestron Flex tabletop conferencing device
Touch Screen 7 in. (178 mm) diagonal capacitive multi‑touch TFT active matrix color LCD, 1280 x 800 pixels
UI Zoom Rooms UI
Mic Mute Symbol & Light Bar (2) Capacitive buttons with bi‑color LEDs, either button toggles between mute and unmute
AEC Limes Audio TrueVoice® acoustic echo cancellation, automatic mic mixing, automatic gain control, and dynamic noise reduction; full‑duplex IEEE 1329 Type 1 compliant
Speaker Full range speaker, 11 W amplifier power, 95 dB SPL at 0.5 m maximum output, 90 Hz to 22 kHz frequency response
Microphones 360° quad mic array, 20 ft (6 m) typical pickup range
Extension Microphones Supports two mic pods, model CCS‑UCA‑MIC (sold separately)
Occupancy Sensor 6 ft (1.8 m) PIR range in front of touch screen
Ethernet 100 Mbps; enterprise grade security and management including IEEE 802.1X, Active Directory® authentication, LDAP, Kerberos, SSL, TLS, SSH, SFTP (SSH File Transfer Protocol), SRTP, digest access authentication, password login, HTTPS secure provisioning, XiO Cloud service
USB USB 2.0 micro Type B device port, supports UAC for audio interface to UC Engine (model UC-ENGINE-P) (cable included)
Power 24 VDC via external 100‑240 VAC, 50/60 Hz power pack, model PW‑2420RU(included)

NOTE: The CCS-UC-1-X cannot be powered by Power over Ethernet or PoE+.
Dimensions Height: 4.11 in. (104 mm)
Width: 8.92 in. (227 mm)
Depth: 12.74 in. (324 mm)
Weight 5.50 lb (2.5 kg)
Microphone Pod
Model CCS-UCA-MIC
Communications A2B bus protocol, slave, synchronous data, multichannel I2S/TDM to I2S/TDM
Microphone Triple mic array with (3) cardioid electret elements
Pickup Range 20 ft (6 m) typical, 360°
Mic Mute (1) Capacitive button with bi-color LED, toggles between mute and unmute (affects all system mics)
Connectors (2) RJ9 4P4C connector, female
Power Powered via the CCS-UC-1-X through the A2B bus
Dimensions Height: 0.97 in. (25 mm)
Width: 3.81 in. (97 mm)
Depth: 3.42 in. (87 mm)
Camera
Wide Field of View 82°
Connectivity USB Type-C® connector
Power 12 VDC power adapter
Resolution/FPS HD 1080p @ 30 fps
Dimensions Height: 7.17 in. (182 mm)
Width: 6.02 in. (153 mm)
Depth: 5.63 in. (143 mm)
UC Bracket Assembly
Mini PC Intel Core® processor with Windows® 10 IOT Edition OS, and 100/1000 Mbps Ethernet connectivity
UC Client Zoom Rooms Software
Management Client XiO Cloud service
Content Ingest HDMI input via HDMI to USB 3.0 converter (model HD‑CONV‑USB‑250)
Display Output Single or dual display support
Display Output Resolution 1080p
Power 90 W via external 100‑240 VAC, 50/60 Hz adapter (included)
Construction Metal mounting bracket, black, preassembled with UC Engine (model UC‑ENGINE-P‑Z) and USB to HDMI converter (model HD‑CONV‑USB‑250)
Mounting Surface wall mount behind the display device, or attach to the rear of the display device via the bolts attaching the display to a VESA® compliant display mount; the bracket includes mounting holes on both side edges, spaced 100, 200, and 300 mm vertically, to allow for attachment to either side of the display mounting plate
Dimensions Height: 15.00 in. (381 mm)
Width: 14.50 in. (368 mm)
Depth: 1.72 in. (44 mm)
